Keychron Lemokey L1 QMK/Via Fully Assembled With Knob RGB Backlit Hot-Swappable 75% Wireless Custom Gaming Keyboard - Carbon Black (Gateron Jupiter Red Switch) (L1-M1)
Lemokey's L1 is a custom wireless mechanical keyboard designed for gaming enthusiasts, featuring a 75% layout QMK/VIA layout. It supports 2.4 GHz wireless, Bluetooth, and wired modes, and supports up to 3 devices for seamless multitasking. The keyboard is made of 6030 aluminum and features premium non-shine Cherry PBT keycaps, a double-gasket mount design, and a flexible PC plate.
Features:
- 2.4GHz & Bluetooth Wireless Connection
- Double-Shot PBT Keycaps
- 1000 Hz Polling Rate
- Double-Gasket Structure
- QMK/VIA Support
- Hot-Swappable
- Ultra-Low Latency
- CNC Aluminum Body
Specification:
| Dimension | 369 x 146 mm (14.5 x 5.75 inches) |
|---|---|
| Number of Keys | 86 (75% layout) |
| Layout | ANSI (US) Fully Asssembled and Barebone/ISO (EU) Barebone |
| Back Height without keycaps | 33.04 mm (1.30 inches) |
| Front Height without keycaps | 21.03 mm (0.83 inches) |
| Front Height with keycaps | 29,06 mm (1.14 inches) |
| Weight | About 1887 g (Fully Assembled version) |
| Frame Material | Full CNC machined aluminum |
| Plate Material | PC |
| Keycap | Cherry double-shot PBT keycaps (Non-backlight shine through) |
| Switch | Gateron Jupiter (Fully Assembled version) |
|---|---|
| Stabilizer | Screw-in PCB stabilizer |
| Switch Face | South-facing RGB |
| Backlight | 22 types of RGB backlight options plus endless possibilities |
| Hot-swappable | Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc. |
| MCU | ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
| Cable Length | 1.8 m |
| Polling Rate | 1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode) |
| N-Key Rollover (NKRO) | Yes for both wireless and wired modes |
| Operating Environment | -10 to 50℃ |
| Battery | 4000 mAh Rechargeable li-polymer battery |
|---|---|
| BT Working Time (Backlit off) | Up to 200 hours (Lab test result may vary by actual use) |
| BT Working Time (RGB) | Up to 100 hours (Lowest brightness) |
| Charging Time | Around 5 hours |
| Charging Port | USB type-C |
| Bluetooth Version | 5.1 |
| Compatible System | Windows/macOS/Linux |
| Connectivity | 2.4 GHz/Bluetooth / Type-C wired |
| Bluetooth Device Name | Lemokey L1 |
| Bluetooth Operating Distance | Within 10 meters (Open space) |
